Browse / Parts & Components / Rigid Top Plate Caster – Silver 6 Inch by 2 Inch V-Groove Semi Steel Cast Iron Wheel – Bronze Bearing – 450 lbs. Capacity Per Caster – Service Caster Brand
Rigid Top Plate Caster – Silver 6 Inch by 2 Inch V-Groove Semi Steel Cast Iron Wheel – Bronze Bearing – 450 lbs. Capacity Per Caster – Service Caster Brand
Seller
Sign in to see direct contact details and connect off-platform, or message through CynchUp.
View seller's listingsDetails
- Manufacturer
- Service Caster
- Model
- Series #20
- SKU
- SCC-20R620-VGBZ
- Condition
- new
- Quantity
- 1
- UPC
- 734005086812
- Harmonized code
- 8302.20.0000
- Dimensions (L x W x H)
- 8 x 8 x 8 in
- Shipping weight
- 9 lb
- Posted
- Sep 17, 2026, 7:00 PM CDT
Specifications
- Bolt Pattern
- 1-3/4" x 2-7/8" to 3"
- Bolt Size
- 5/16" (hardware not included)
- Capacity
- 450
- Color
- Rigid - No Brake - Silver
- Heat Capacity
- -45 degrees F to 180 degrees F
- Item Dimension Unit of Measure
- inches
- Item Weight Unit of Measure
- pounds
- Load Height
- 7-1/2"
- Lower Temperature
- -45
- Lower Temperature UofM
- F
- Material Type
- V-Groove Semi Steel
- Maximum Temperature
- 180
- Maximum Temperature UofM
- F
- Mounting Height
- 7-1/2"
- Mounting Type
- Top Plate
- Plating/Coating
- Bright Zinc Plated Finish
- Casters Mounting Method
- Plate
- Size
- 6" Wheel
- Top Plate Size
- 2-3/8" x 3-5/8"
- Tread Width
- 2
- Tread Width UofM
- inches
- Type
- Rigid Caster
- Wheel Bearing
- Bronze Bearing
- Wheel Diameter
- 6
- Wheel Diameter UofM
- inches
- Wheel Material
- V-Groove Semi Steel Cast Iron
- Wheel Size
- 6" x 2"
- Wheel Type
- V-Groove Semi Steel
Description
Listing is for one (1) Service Caster Series #20 rigid caster with a 6" diameter by 2" wide v-groove semi steel cast iron wheel with a bronze bearing capable of supporting 450lbs./caster. When searching for a reliable and durable solution for heavy duty projects, consider Service Caster’s Series 20 top plate semi steel cast iron v-groove wheel casters. The Service Caster Series #20 v-groove wheel is designed to roll on 45 degree angled track, and also has a flat face suitable for non-tracked use. The semi-steel cast iron wheel is built to withstand high capacity, heavy loads up to 450lbs and in temperatures up to 600°F. An economic choice over steel, semi-steel wheels are abrasion resistant and rugged. Finely crafted with double ball bearing heat treated raceways, these versatile casters are ideal for a wide range of applications specific to high capacity tracked workflows, but also for dollies, platform trucks, warehouse carts and freight terminals. Or ensure a smooth and secure ride for industrial and commercial equipment. Even drywall carts, welding carts, and wall panel carts will be ready to roll on the Series 20, keeping you moving forward. Service Caster is unsurpassed in quality, reliability, and excellent customer service. Count on us to move you forward. • These Service Caster Series #20 V-Groove Semi Steel Caster Iron casters offer various wheel sizes and mounting heights: 4” Wheel: 5-1/8” mounting height; 5” wheel: 6-1/8” mounting height; 6” wheel: 7-1/2” mounting height. • Weight Capacity: 4", 5", 6": 450 lbs Capacity/Caster • Top plate measures at 2-3/8" x 3-5/8" with a bolt hole pattern of 1-3/4" x 2-7/8" to 3" and can either be bolted or welded on. • Brake options include a top lock brake (TLB). The top lock brake (TLB) places a positive locking force against the wheel tread locking the wheel only.
