Browse / Parts & Components / 461C6DBA C6DBA Metro 6 Inch Swivel Caster with Brake - Fits Metro D2130SP D2136NCB D2136NP D2136SCB D2136SP D2142NCB - Heavy Duty Replacement – Thermoplastic Rubber Wheel - Service Caster Brand
461C6DBA C6DBA Metro 6 Inch Swivel Caster with Brake - Fits Metro D2130SP D2136NCB D2136NP D2136SCB D2136SP D2142NCB - Heavy Duty Replacement – Thermoplastic Rubber Wheel - Service Caster Brand
Seller
Sign in to see direct contact details and connect off-platform, or message through CynchUp.
View seller's listingsDetails
- Manufacturer
- Service Caster
- Model
- Series #30
- SKU
- MET-SCC-20S620-TPRR-D-TLB
- Condition
- new
- Quantity
- 1
- UPC
- 734005218442
- Harmonized code
- 8302.20.0000
- Dimensions (L x W x H)
- 8 x 8 x 8 in
- Shipping weight
- 6 lb
- Posted
- Sep 17, 2026, 7:00 PM CDT
Specifications
- Bolt Pattern
- 1-3/4" x 2-7/8" to 3"
- Bolt Size
- 5/16" (hardware not included)
- Capacity
- 450
- Color
- Swivel - Top Lock Brake - Top Plate
- Durometer
- 70A
- Heat Capacity
- -45 degrees F to 180 degrees F
- Item Dimension Unit of Measure
- inches
- Item Weight Unit of Measure
- pounds
- Load Height
- 7-1/2"
- Locking Type
- Top lock brake
- Lower Temperature
- -45
- Lower Temperature UofM
- F
- Material Type
- Thermoplastic Rubber Tread on Polyolefin Core
- Maximum Temperature
- 180
- Maximum Temperature UofM
- F
- Mounting Height
- 7-1/2"
- Mounting Type
- Top Plate
- Plating/Coating
- Bright Zinc Plated Finish
- Casters Mounting Method
- Plate
- Locking Castersor Wheels
- Yes
- Swivels
- Yes
- Size
- 6" Thermoplastic Rubber Wheel
- Top Plate
- 2-3/8" x 3-5/8"
- Top Plate Size
- 2-3/8" x 3-5/8"
- Tread Width
- 2
- Tread Width UofM
- inches
- Type
- (1) swivel caster w/top lock brake
- Wheel Bearing
- Roller Bearing
- Wheel Diameter
- 6
- Wheel Diameter UofM
- inches
- Wheel Material
- Thermoplastic Rubber Tread on Polyolefin Core
- Wheel Size
- 6" x 2"
- Wheel Type
- Thermoplastic Rubber Tread on Polyolefin Core
Description
When searching for a reliable and durable solution to your Metro replacement caster needs, consider Service Caster’s Series 20 top plate thermoplastic rubber donut tread on polyolefin core casters. The rounded face "donut" style soft tread is made of thermoplastic rubber that is non-marking, non-marring and provides easier mobility over standard flat tread wheels, resulting in a long lasting, high capacity wheel capable of easy rolling under heavy loads. Finely crafted with double ball bearing heat treated raceways, these versatile casters are ideal for a wide range of applications, such as dollies, platform trucks, warehouse carts and freight terminals. Or ensure a smooth and secure ride for food service carts, hotel housekeeping carts, and industrial and commercial equipment. Even drywall carts, welding carts, and wall panel carts will be ready to roll on the Series 20, keeping you moving forward. These casters are commonly used on Metro truck dollies. Service Caster is unsurpassed in quality, reliability, and excellent customer service. Count on us to move you forward. • Fits Metro Truck Dollies • Compatible Models: M D2130SP, M D2136NCB, M D2136NP, M D2136SP, M D2142NCB, M D2142NP, M D2142SP, M D2148NCB, M D2148NP, M D2148SCB, M D2148SP, M D2160NCB, M D2160NP, M D2160SCB, M D2160SP, M D2172NCB, M D2172NP, M D2172SCB and M D2172SP • Weight Capacity: 450 lbs. Capacity Per Caster • HARDWARE NOT INCLUDED
