461B5P B5P Metro 5 Inch Swivel Caster - Fits Metro Models D1824NCB D1824NP D1824SCB D1824SP D1830NCB D1830NP D1830SCB - Light Duty Replacement - Maroon Polyurethane Wheel - Service Caster Brand

Details

Manufacturer

Service Caster

Model

Series #20

SKU

MET-SCC-20S514-PPUB-MRN

Condition

new

Quantity

1

UPC

734005217391

Harmonized code

8302.20.0000

Dimensions (L x W x H)

8 x 8 x 8 in

Shipping weight

6 lb

Posted

Sep 17, 2026, 7:00 PM CDT

Specifications

Bolt Size

5/16" (hardware not included)

Capacity

350

Color

Swivel - No Brake - Top Plate

Durometer

60D

Heat Capacity

-20 degrees F to 180 degrees F

Item Dimension Unit of Measure

inches

Item Weight Unit of Measure

pounds

Load Height

6-1/8"

Lower Temperature

-20

Lower Temperature UofM

F

Material Type

Polyurethane Tread on Polyolefin Core

Maximum Temperature

180

Maximum Temperature UofM

F

Mounting Height

6-1/8"

Mounting Type

Top Plate

Plating/Coating

Bright Zinc Plated Finish

Casters Mounting Method

Plate

Swivels

Yes

Size

5" Maroon Polyurethane Wheel

Top Plate Size

2-1/2" x 3-5/8"

Tread Width

1.25

Tread Width UofM

inches

Type

Swivel caster

Wheel Bearing

Precision Ball Bearing

Wheel Diameter

5

Wheel Diameter UofM

inches

Wheel Material

Polyurethane Tread on Polyolefin Core

Wheel Size

5" x 1-1/4"

Wheel Type

Polyurethane Tread on Polyolefin Core

Description

Listing is for one (1) Service Caster Series #20 swivel caster with a 5" diameter by 1-1/4" wide maroon polyurethane wheel capable of supporting 350 lbs. per caster. 461B5P B5P replacement part fits Metro truck dollies and shelving units. When searching for a reliable and durable solution to your Metro replacement caster needs, consider Service Caster Series 20 top plate polyurethane tread on polyolefin core wheel casters. The Service Caster Series #20 features polyurethane tread on polyolefin core wheels that offer a softer tread for smoother travel while also resisting damage from debris. Finely crafted with a bright zinc plated finish and heat-treated ball bearing raceway, these Service Caster high performance Metro replacement casters balance high pay loads with smooth and quiet operation. These versatile casters are ideal for a wide range of applications, but are commonly used on Metro truck dollies and shelving units. Service Caster is unsurpassed in quality, reliability, and excellent customer service. Count on us to move you forward. • Fits Metro Truck Dolly • Compatible Models: D1824NCB, D1824NP, D1824SCB, D1824SP, D1830NCB, D1830NP, D1830SCB, D1830SP, D1836NCB, D1836NP, D1836SCB, D1836SP, D1842NCB, D1842NP, D1842SCB, D1842SP, D1848NCB, D1848NP, D1848SCB, D1848SP, D1860NCB, D1860NP, D1860SCB, D1860SP, D1872NCB, D1872NP, D1872SCB, D1872SP, D2124NCB, D2124NP, D2124SCB, D2124SP, D2130NCB, D2130NP, D2130SCB, D2130SP, D2136NCB, D2136NP, D2136SCB, D2136SP, D2142NCB, D2142NP, D2142SCB, D2142SP, D2148NCB, D2148NP, D2148SCB, D2148SP, D2160NCB, D2160NP • Weight Capacity: 350 lbs. Capacity Per Caster • HARDWARE NOT INCLUDED
