Browse / Parts & Components / 240CPS54H Channel 4 Inch Swivel Caster – Fits Channel Models 400A-OR 400S-OR 401A-OR 401S-OR 402A-OR 402S-OR 403A-OR - Light Duty Replacement – High Temp Glass Filled Nylon Wheel- Service Caster Brand
240CPS54H Channel 4 Inch Swivel Caster – Fits Channel Models 400A-OR 400S-OR 401A-OR 401S-OR 402A-OR 402S-OR 403A-OR - Light Duty Replacement – High Temp Glass Filled Nylon Wheel- Service Caster Brand
Seller
Sign in to see direct contact details and connect off-platform, or message through CynchUp.
View seller's listingsDetails
- Manufacturer
- Service Caster
- Model
- Series #20
- SKU
- CHA-SCC-20S415-GFNSHT-TP2
- Condition
- new
- Quantity
- 1
- UPC
- 734005218763
- Harmonized code
- 8302.20.0000
- Dimensions (L x W x H)
- 5 x 5 x 5 in
- Shipping weight
- 4 lb
- Posted
- Sep 17, 2026, 7:00 PM CDT
Specifications
- Bolt Pattern
- 1-3/4" x 2-7/8" to 3"
- Bolt Size
- 5/16" (hardware not included)
- Capacity
- 350
- Color
- Swivel - No Brake - Top Plate
- Durometer
- 85D
- Heat Capacity
- -20 degrees F to 180 degrees F
- Item Dimension Unit of Measure
- inches
- Item Weight Unit of Measure
- pounds
- Load Height
- 5-1/8"
- Lower Temperature
- -20
- Lower Temperature UofM
- F
- Material Type
- High Temperature Glass Filled Nylon
- Maximum Temperature
- 180
- Maximum Temperature UofM
- F
- Mounting Height
- 5-1/8"
- Mounting Type
- Top Plate
- Plating/Coating
- Bright Zinc Plated Finish
- Casters Mounting Method
- Plate
- Swivels
- Yes
- Size
- 4" High Temp Glass Filled Nylon Wheel
- Top Plate
- 3-1/8" x 4-1/8"
- Top Plate Size
- 3-1/8" x 4-1/8"
- Tread Width
- 1.5
- Tread Width UofM
- inches
- Type
- (1) swivel caster
- Wheel Bearing
- Plain Bore
- Wheel Diameter
- 4
- Wheel Diameter UofM
- inches
- Wheel Material
- High Temperature Glass Filled Nylon
- Wheel Size
- 4" x 1-1/2"
- Wheel Type
- High Temperature Glass Filled Nylon
Description
Listing is for one (1) Service Caster Series #20 swivel caster with a 4" diameter by 1-1/2" wide high temperature glass filled nylon wheel capable of supporting 350 lbs. per caster. 240CPS54H replacement part fits select Channel equipment. When searching for a reliable and durable solution to your Channel replacement caster needs, consider Service Caster Series 20 top plate high temp glass filled nylon wheel casters. The Service Caster Series #20 is ideal for autoclaves, bakery ovens and powder coating facilities. The zinc plated finish provides durability under any condition, and the high temp glass filled nylon wheels- quieter than comparable steel wheels- have a high resistance to impact damage, providing protection for floors in commercial and industrial settings. This caster is ideal for use in high temperatures associated with baking, performing consistently in temperature ratings of 475°F continuous usage to 550°F intermittent usage. Not only are they resistant to water, oil, and grease, but because they are non-metallic, these wheels are spark proof, keeping you safely moving forward. Service Caster is unsurpassed in quality, reliability, and excellent customer service. Count on us to move you forward. • Fits Select Channel Equipment • Compatible Models: 400A-OR, 400S-OR, 401A-OR, 401S-OR, 402A-OR, 402S-OR, 403A-OR, 403S-OR, 404A-OR, 404S-OR, 410A-DOR, 410A-OR, 410S-DOR, 410S-OR, 411A-DOR, 411A-OR, 411S-DOR, 411S-OR, 412A-DOR, 412A-OR, 412S-DOR, 412S-OR, 413A-DOR, 413A-OR, 413S-DOR, 413S-OR, 414A-DOR, 414A-OR, 414S-DOR and 414S-OR • Weight Capacity: 350 lbs. Capacity Per Caster • HARDWARE NOT INCLUDED
